Bus (-) Open

Tests 1 - 3:

SYMPTOM
BUS (-) OPEN

TEST NOTE
This symptom is diagnosed using the test BUS (+) OPEN.

POSSIBLE CAUSES
- CCD bus (+) or bus (-) circuit open
- DRB OR DRB cable
- Instrument cluster bus (+)/(-) open
