Power Distribution: Diagrams

8w-10-6:

Battery
Fuse 2 (PDC)
Fuse 3 (PDC)
Fuse 4 (PDC)
Fuse 5 (PDC)
Fuse 6 (PDC)
Fuse 7 (PDC)
Fuse 8 (PDC)
Fuse 11 (PDC)
Fuse 12 (PDC)
Fuse 13 (PDC)
Fuse 14 (PDC)
Fuse 15 (PDC)
Fuse 16 (PDC)
Fuse 17 (PDC)
Fuse 18 (PDC)
Fuse 19 (PDC)
Power Distribution Center

8w-10-7:

Controller Anti-Lock Brake
Downstream Heated Oxygen Sensor
Fuse 1 (PDC)
Fuse 2 (PDC)
Fuse 3 (PDC)
Power Distribution Center
Transmission Control Module
Transmission Relay
Transmission Solenoid And Pressure Switch Assembly
S100

8w-10-8:

Automatic Shut Down Relay
Combination Flasher
Combined Rear Lighting Module
Fuse 1 (PDC)
Fuse 4 (PDC)
Fuse 5 (JB)
Fuse 5 (PDC)
Fuse 6 (PDC)
Junction Block
Power Distribution Center
Powertrain Control Module
Stop Lamp Switch
S104

8w-10-9:

Engine Starter Motor
Engine Starter Motor Relay
Fuel Pump Module
Fuel Pump Relay
Fuse 8 (PDC)
G301
Ignition Switch
Instrument Cluster
Junction Block
Power Distribution Center
S102

8w-10-10:

Body Control Module
Engine Starter Motor Relay
Fuse 9 (PDC)
Fuse 10 (PDC)
Fuse 11 (JB)
Fuse 14 (JB)
Fuse 15 (JB)
Fuse 17 (JB)
Ignition Switch
Junction Block
Power Distribution Center
Transmission Control Module

8w-10-11:

A/C Compressor Clutch Relay
Fuse 9 (PDC)
High Speed Radiator Fan Relay
Instrument Cluster
Low Speed Radiator Fan Relay
Power Distribution Center
Vapor Canister Leak Detector
S106

8w-10-12:

Controller Anti-Lock Brake
Fuel Pump Relay
Fuse 10 (PDC)
Fuse 11 (PDC)
Power Distribution Center
Power Top Up/Down Relays
Powertrain Control Module
S105

8w-10-13:

Fuse 12 (PDC)
Fuse 7 (JB)
Fuse 8 (JB)
Fuse 13 (PDC)
Fuse 14 (PDC)
Intermittent Wiper Relay
Junction Block
Power Distribution Center
Seat Belt Control Module
Windshield Wiper Motor

8w-10-14:

Body Control Module
Circuit Breaker 18 (JB)
Fuse 9 (JB)
Fuse 10 (JB)
Fuse 12 (JB)
Fuse 13 (JB)
Fuse 15 (PDC)
Headlamp
Headlamp Switch
Junction Block
Power Distribution Center

8w-10-15:

A/C Compressor Clutch
A/C Compressor Clutch Relay
Fuse 6 (JB)
Fuse 16 (PDC)
Fuse 17 (PDC)
High Speed Radiator Fan Relay
Junction Block
Low Speed Radiator Fan Relay
Power Distribution Center
Radiator Fan Motor Assembly
Rear Window Defogger
Rear Window Defogger Relay
S103

8w-10-16:

Circuit Breaker 19 (JB)
Controller Anti-Lock Brake
Fuse 4 (JB)
Fuse 1 (JB)
Fuse 16 (JB)
Fuse 18 (PDC)
Fuse 19 (PDC)
Ignition Switch
Junction Block
Power Distribution Center

NOTE: To view sheets referred to in these diagrams, see Complete Body and Chassis Diagrams Diagrams By Group Number.
